3D Print Fill

Discussion in 'Halo Props' started by Chisum, Feb 1, 2019.

  1. Chisum

    Chisum New Member

    Trophy Points:
    5
    I previously printed a BR 55 Battle Rifle with a 60% fill. Dropped it once at Con and it shattered into 6 pieces. Looking for recommendations on a better fill ratio on the print?

  2. TurboCharizard

    TurboCharizard RMO & BCO 405th Regiment Officer Community Staff

    Trophy Points:
    1,085
    24% is my magic number for one printer and 20% for the other. Those values are the lowest I go to prevent pillowing on the top surfaces while keeping weight of the prop down. I've never had a shatter, what was the adhesive you used?

  3. Chisum

    Chisum New Member

    Trophy Points:
    5
    Locite Epoxy and Bondo. Only one seem broke, the rest were fractures in the print. Must have just perfect when I dropped it from the truck and struck butt first.

  4. Masky

    Masky RMO 405th Regiment Officer

    Trophy Points:
    125
    I found perimeters do more than infill for strength. I print most of my stuff with 10% but 3 perimeters. I can recommend looking into ABS as well, dropped a prop before and got only a few scratches and dents in it.

    TurboCharizard and Chisum like this.
  5. arma358

    arma358 PR Officer Division Staff

    Trophy Points:
    105
    So, as an engineer IRL, there's a very very good reason that perimeters add more strength vs. more infill. If you think of a beam of material, say steel....and you try to bend it, primarily the top and the bottom parts of the steel are bending the most. So, if you have more solid material in a part along the outer edges, the more bending you can take up before it breaks! :)

  6. Chisum

    Chisum New Member

    Trophy Points:
    5
    Thanks for the input, I will definitely make sure I try this next print

  7. Masky

    Masky RMO 405th Regiment Officer

    Trophy Points:
    125
    Oh boy I remember that subject and the horrible math

    TurboCharizard and arma358 like this.
  8. arma358

    arma358 PR Officer Division Staff

    Trophy Points:
    105
    I mean....bending is no joke! :p

    TurboCharizard likes this.
  9. Sean Anwalt

    Sean Anwalt RCO 405th Regiment Officer

    Trophy Points:
    1,035
  10. TurboCharizard

    TurboCharizard RMO & BCO 405th Regiment Officer Community Staff

    Trophy Points:
    1,085
    This is why I went CEng, I'll whip up a controller for you or be a code monkey but finite element analysis gets me sweating.

    Material properties are also another consideration along with print settings. I'm not sure about all brands of filament but eSun includes a data sheet for all of their materials in every box. The particularly handy entries when choosing a material for props are the tensile yield strength, flexural modulus and impact strength to help gauge how well a piece will react to clumsiness.

    xXDashIVXx likes this.
  11. Bucs37DK

    Bucs37DK Active Member

    Trophy Points:
    265
    We print in 5% infill with 5 perimeters. The durability is excellent. As stated previously here, the perimeters are extremely important to strength.
